Unparalleled power. Rifle-like accuracy.
Our fastest, most powerful compact crossbow, the R500 takes industry-leading Ravin technology to new heights. Big game, long range, there's nothing an apex hunter can't achieve with an R500 crossbow at their side.

With off-the-charts kinetic energy, the R500 shoots faster and farther without sacrificing any legendary Ravin accuracy. It extends your maximum effective and ethical range to 100 yards.

The engineering behind Ravin HexCoil cam systems boosts speeds to over 500 fps. And our groundbreaking VersaDrive Cocking System gives hunters far more control over their shot. With it, you can cock, decock, pause, or resume the process at any time, with no chance of over-cocking - all silent as a shadow.

Specifications:
Speed (400 gr.): 500 fps
Kinetic Energy: 222.0 ft-lbs
Width Axle-Axle: 3.6&quote; Cocked
Width Axle-Axle: 7.6&quote; Un-Cocked
Power Stroke: 15&quote;
Product Weight: 8.4 lbs
Length: 28.5?
Draw Force: 17 lbs
Powered By: Hexcoil Cam System
Limbs: Fiberglass
Riser: Aluminum CNC
Stock Material: Nylon Fiber
Color: Slate Gray

Ravin R500 series bows include all the latest Ravin innovations to deliver the apex of crossbow accuracy and power.

Each comes fully assembled and pre-tuned with:
Anti-dry fire and auto safety
Built-in sling mounts
Adjustable cheek pad
Adjustable buttstock
3x .003 R500 Series Arrows & field points (400 grain total)
Removable draw handle
Quiver with mounting bracket
100-Yard Illuminated 550 Scope

100-Yard Illuminated Crossbow Scope:
30 - 100 yard reticles
Red & green illumination
Fog, shock, recoil, and waterproof
Fully coated lenses

01 VERSADRIVE COCKING SYSTEM
The internal screw drive moves the Trac Trigger Firing System (TTFS) back and forth and an internal clutch eliminates over-cocking, allowing cocking and uncocking to be stopped or resumed at any time during the process.

02 HEXCOIL CAM SYSTEM
A proprietary system rotates cams an incredible 360 degrees, reforming traditional crossbows into the fastest, most accurate and compact designs ever seen.

03 VERSADRIVE COCKING SYSTEM
The internal screw drive moves the Trac Trigger Firing System (TTFS) back and forth and an internal clutch eliminates over-cocking, allowing cocking and uncocking to be stopped or resumed at any time during the process.

04 FRICTIONLESS™ FLIGHT SYSTEM
This patented technology allows the arrow and string to free float above the rail, eliminating friction for consistent accuracy and increased string and cable life. This unique HeliCoil advantage delivers astounding target accuracy with every shot.

05 SILENT COCKING
The Fully Integrated Silent Cocking System works in conjunction with the Trac Trigger Firing System and includes a built-in one way bearing removing any noise, resulting in a completely silent draw. The cocking mechanism allows you to stop the draw cycle at any time during the cocking process. They'll never hear you coming.
